SMD5050 RGB LED Module IP68 JR-K3C-RGB

Specifications:

Power:  0.72 W

Working Voltage: DC12V

LED Type: 5050 SMD LED

LED BRAND: chip from Epistar

Available Color： RGB

LED Qty: 3PCS*RGB SMD5050

Viewing Angle: 160degree

Life Span: 50,000 Hours

Stand Length In Serial Connection: 50pcs

Maximum Length In Serial Connection: 50pcs

Shell： white ABS

IP Degree : IP68

Dimension: 66*15*7.5 MM

Certification: CE&ROHS

Working Temperature：  -20degree ~+60degree

Store Temperature : -50degree ~ +60degree

Product Features:

1. Adopt TOP 5050 RGB SMD LED, no light spot, with low lumen recession and good consistency.
2. With a low power consumption and high lumen value, RGB color, a long life-span, maintenance-free.

3. With a plastic injection technique for outer cover, this unique structure grants a better cooling effect. UL94V0 ABS.
4. IP Rate: IP68,waterproof.
5. DC 12V low voltage input, reliable and safe.
6. Adopt series-parallel connection circuit,  50 pcs per string, each module could be singled out.
7. Viewing angle: 120degree
8. Epistar chip is 3 years warranty.
